Semi-automatic packaging machine 25 kg weighing bag rice semi-automatic packaging machine 50 kg feed fertilizer granule packaging machine

Semi-automatic bag-packing and box-packing granule powder packaging machine

• BrandBENSON
• OriginShandong, China
• Voltage220V 380V 50Hz
• Dimensions (l*w*h)3260*1100*2600
• Air pressure volume0.5~0.6MPa 0.36m3/min
• Packaging speed200-300 bags/hour
• FunctionFilling, Packing, Sealing
• Core ComponentsMotors, pressure vessels, PLCs, gears, bearings, engines, gearboxes

Inquiry about this product

Inquiry about this product

Video Description

PRODUCTS DESCRIPTION
The unit consists of the ration automatic packing scale and the selecting and matching parts: elevator, conveyor and the hemming
machine.It uses gravity feed, feed transmission device is suitable for powdery granular mixture, irregular sheet and block
materials, poor fluidity of the material design. The main components are: storage hopper, feeder, weighing clamping box, computer
box, computer control, pneumatic actuator.
When the particle packaging machine enters the automatic operation state, the weighing control system opens the feeding door to start feeding. The feeding device is a fast and slow feeding mode. When the material weight reaches the set value of fast feeding, the fast feeding is stopped and the slow feeding is maintained. When the material weight reaches the set value, the feeding door is closed to complete the dynamic weighing process. At this time, the system detects whether the bag clamping device is in When the bag has been clamped, the system will send a control signal to open the unloading door of the weighing bucket, and the material will enter the bag. After the material is put out, the unloading door of the weighing bucket will be closed automatically; after the material is unloaded, the bag clamping device will be released and the bag will fall down automatically; after the bag is dropped, the bag will be sewn and transported to the next station. In this way, it operates automatically.

PRODUCT DESCRIPTION

Power Supply：AC 220V/380V 50 HZ 1P/3P Customized

Air Source:0.4~0.6MPa 0.36m³/min

Application Materials:Applicable for materials such as: compost, gravel, rare earth, bentonite, river sand, mortar, organic fertilizer, microbial fertilizer, barite, gypsum, flakes, irregular shaped pieces, bolts, screws, nuts etc.

Application:
Shandong BENSON Automation Co., Ltd. is one of the fastest growing packaging machinery factories in China,specialized in the research, design, manufacture, marketing and service of packaging machines which are widely used in different fields such as food, chemicals, medicines, beverage, light industry, etc. quantitative packaging scales and supporting equipment.
Packing Machine Workflow:
Giving the bag (loading the bag) → automatically clamps the bag→ material is automatically quantitatively weighed and filled into bags→ automatic bag release /bag holding/bag transfer→ automatic label feeding /folding /or heat sealing/or sewing→ entering the next process such as stacking on pallet and wrapping.

Automatic and Manual mode.

Designed to suit open mouth bags.
Multiple product types can be bagged.
Easy to clean, easy to maintain.
Can be customized according to customer requirements.
-The adaptive software, having the function of automatic control parameters setting, automatic drop revising, over-weight warning and auto-diagnosis.
-Wide packing range, high precision, it can match well with conveyor and sewing machine.
-Products using imported sensor, pneumatic actuator, easy maintenance and non-pollution.

OPTIONAL

*OUR CONFIGURATION

PROJECT DISPLAY

PACKAGING & DELIVERY

COMPANY PROFILE

BENSON Intelligent Equipment (Shandong) Co., Ltd. is a modern high-tech enterprise, focusing on the research and development of industrial robots, palletizing robots, palletizers, high-position palletizers, fully automatic bagging packaging machines, packaging machines, batching equipment, depalletizers, loaders, logistics automation lines and other projects. The company has brought together a group of high-level and high-quality professionals. The company actively promotes the development model of “production, learning and research” and has successfully developed a new generation of automated production lines that can be widely used in automated packaging and automated logistics engineering. Its capabilities and various technical indicators are at a high level. In order to comprehensively improve its market competitiveness, the company has selected a large number of high-quality accessories from the United States, Japan, Europe and other countries, and introduced various advanced processing equipment to greatly improve the quality of its products. It has been widely used in chemical, feed, flour, building materials, food, beverages, beer, automated logistics and other industries. From product import to output, from electrical control to mechanical structure design, BENSON Intelligent Equipment (Shandong) Co., Ltd. can fully provide system technical solutions and precision manufacturing of equipment. At the same time, we have a complete after-sales service system to provide you with high-quality technical support and after-sales service.

FAQ

Title goes here.

Q1: May I know how long it takes to get the machine after transfer?

A1: Usually, if the machine you need is a standard type, we can ship it within 7 days. Customized types are welcome, and the delivery time is about 20-25 working days.

Q2: How long is the product warranty period?

A2: The product warranty period is 12 months.

Q3: Can you help me pack other goods together into the container?

A3: Yes, of course. If most of the products are purchased from us, and other products are also purchased from other suppliers, you can ask other suppliers to send the products to our factory (Tai’an City, Shandong Province). We help you pack all your products into one container. Arrange everything.

Q4: After the machine is finished, how to check the quality of the machine?
A4: We have made video calls with customers in seminars for on-site inspection on zoom, Microsoft, Teamviewer, whatspp, skype and wechat.
